Technical parameters
1. Input Power: DC 12V10A
2. Box Size: 420 * 560 mm
3. Voice coil motor: 12V1A
4. Weight: 52kg
5. Operating Noise: no-load < 68 db
6. Vibration mode: 11 programmable vibration modes
7. Control system: self-developed special controller
8. Machine interface: 4.3-inch touch screen
9. Protocol: Modbus-rtu and string mode
10. Backlight power supply: with LED backlight power supply
11. Communication interface: 11 RS232 + 1 RS485(can communicate simultaneously)
12. Digital interface: four digital inputs and one digital output
13. Warranty service: one year warranty (to be repaired)
14. List of accessories: controller +flex feeder+matching wiring harness
15. Working Frequency: the default 10 ~ 99 can open more frequency range
16. Hopper: hopper can be customized according to the material and provide IO point or communication control interface
17. Reversible weight of a single material: ≤100G varies with the material and shape of the material
External dimensions
